Description
Feature
•H type Head Design: For easy dies replacement and cable inserting
•11 Pairs Standard Dies: For precise crimping, select proper dies according to connector and cable size
•Double Speed Unit: For fast Crimping,allow quick oil delivery under no load condiction, automatically build sufficient working pressure as connectors are contacted.
•Safety Valve equipped: For safe operation, automatically relief working pressure,protect hydraulic system from over pressure
•Plastic Case Package: For easy carrying and protect tool well
Technical Parameters
Model: HP-300
Cu Capacity: 16-300mm2
Output: 12 tons
Max travel: 18 mm
Mould disposition (mm2): 16,25,35,50,70,95,120,150,185,240,300
Size: 490*130*70mm
Weight: 3.8 kg
