Description
AKRON Foam Master Stream Nozzle with Pickup Tube – 4470
The AKRON foam nozzles are self-educating master stream nozzles designed for educating foam at flow rates up to 1000 GPM (4800 LPM).
Features
- Rugged/Corrosion Resistant Brass Construction
- Factory set at 500 gpm (1900 lpm) and field changeable to 350,750, or 1000 gpm (1325,2900, or 3800 lpm)
- Optional Foam Shutoff Valve, Drum Seal Kit & Quick Connect
- Metering capability of 1%, 3%, & 6% for 350 & 500 GPM, and 1% & 3% for 750 & 1000 gpm.
Specifications
| Type | Foam |
| Weight | 25 lbs (11.3 kg) |
| Material | Brass |
| Brand | AkroFoam |
| Length | 12 1/2″ (318 mm) |
| Width | 6″ (152 mm) |
| Height | 9 1/8″ (232 mm) |
| Inlet | 2 1/2” (65 mm) |
| Flow (GPM) | 350-500-750-1000 |
| Flow (LPM) | 1300-1900-2800-3800 |
