Description
Description
Motor Application:
The 1-2HP outdoor unit of split air conditioner
The 2-5HP outdoor unit of split air conditioner
Air purifier
Product Features:
1. Low Noise.
2. Steady quality.
3. Long Expectancy.
4. Large Wind Amount.
5. Imported equipment & technical assistance.
6. Low-temperature rise and strong adaptability to the environment.
7. 100% pure copper, the aluminum motor can also be available if the customer needs a large quantity.
Main Advantages:
1. Shaft diameter or length can be any as customers needs.
2. Stator height can be any from 10mm to 50mm.
3. Mounting holes size and distance can be any as customers’ needs
4. Brackets can be either metal or aluminum. Its height can be changed.
5. Motor rotation direction can be CW or CCW.
6.The motors can be customized according to the different voltages, frequencies and rotation speed.
Technical Parameters:
| Model Number | Output Power
/W |
Voltage
/V |
Frequency
/Hz |
Rated Speed
/RPM |
Rated Current
/A |
| YDK95-20-6 | 20 | 220-240 | 50/60 | 830 | 0.25 |
| YDK95-25-6 | 25 | 220-240 | 50/60 | 830 | 0.27 |
| YDK95-30-6 | 30 | 220-240 | 50/60 | 830 | 0.3 |
| YDK95-35-6 | 35 | 220-240 | 50/60 | 800 | 0.33 |
| YDK95-40-6 | 40 | 220-240 | 50/60 | 850 | 0.4 |
| YDK120-50-6 | 50 | 220-240 | 50/60 | 850 | 0.55 |
| YDK120-55-6 | 55 | 220-240 | 50/60 | 850 | 0.57 |
| YDK120-60-6 | 60 | 220-240 | 50/60 | 850 | 0.6 |
| YDK120-70-6 | 70 | 220-240 | 50/60 | 850 |
